Wilkinson®-Gotoh® VSVG tremolo bridge
The Wilkinson®-Gotoh® VSVG tremolo unit features smooth arm action and the unique design of its elongated baseplate screw holes help promote accurate pitch return by eliminating binding. Its locking bent-steel saddles provide a vintage tone and feel.
Smooth taper volume filter
A smooth taper volume filter maintains the guitars high frequencies at low volumes and provides more uniform tone from 1 to 10.
DiMarzio® The Cruiser® Pickups
The combination of DiMarzio® The Cruiser® pickups deliver single-coil tone, open vocal-sounding mids and a bit of added strength to the bass. These pickups also relieve players of string drop-outs and sustain-killing magnet pull.
Oil-impregnated Bone nut /Stainless Steel Frets
The Oil-impregnated bone nut provides superior tuning stability and warm rich resonance. Stainless steel frets boast excellent corrosion resistance. The wide and tall fret-type offers a quick response, good articulation when playing chords and clear tone when playing single notes.
S-TECH WOOD Roasted Maple fretboard w/Black dot inlay
S-TECH special roasted treatment provides a superior attack and a well-balanced tone and a rich sustain. In order to achieve supreme neck grip comfort, the fretboard edge is finished with a smooth curve.
Gotoh® Magnum Lock machine heads w/H.A.P.(Height Adjustable Post)
The AZ comes with GOTOH® MAGNUM LOCK® machine heads, which have an established reputation for tuning stability. Its H. A. P® (Height Adjustable Post). system allows for the adjustment of string posts for the appropriate tension of each string.
Hardshell case included
Specifications
neck type
ATZ S-TECH WOOD 1pc Roasted Maple neck
top/back/body
Alder body
fretboard
S-TECH WOOD Roasted Maple fretboardBlack dot inlay
fret
Jumbo Stainless Steel fretsPrestige fret edge treatment
number of frets
22
bridge
Wilkinson®-Gotoh® VSVG tremolo bridge
string space
10.8mm
neck pickup
DiMarzio® The Cruiser® (H) neck pickupPassive/Ceramic
middle pickup
DiMarzio® The Cruiser® (H) middle pickupPassive/Ceramic
bridge pickup
DiMarzio® The Cruiser® (H) bridge pickup
factory tuning
1E,2B,3G,4D,5A,6E
strings
D'Addario® EXL110
string gauge
.010/.013/.017/.026/.036/.046
nut
Bone
hardware color
Chrome
NECK DIMENSIONS
Scale :
648mm/25.5"
a : Width
40.5mm at NUT
b : Width
56mm at 21F
c : Thickness
21mm at 1F
d : Thickness
23mm at 12F
Radius :
305mmR
