Large Area Ir Emitter WIRTX9DC Williams AV

THIS PRODUCT IS FOR ONLINE ORDER ONLY. WIR TX9 DCLARGE AREA MULTI-CHANNEL INFRARED EMITTEREnergy-efficient WIR TX9 DC emitter -- now featuring a DC power supply. Improved range - up to 30000 square feet!The powerful WIR TX9 DC emitter produces a wide-angle infrared signal that concentrates IR energy efficiently in the listening area. Operating on the 2.3-3.8 MHz bandwidth the WIR TX9 DC is less susceptible to radio and lighting interference. Each WIR TX9 DC emitter can cover up to 30000 sq. feet (2787 sq. meters) in single-channel operation. The coverage area can be easily increased by daisy-chaining additional WIR TX9 DC emitters. A wall/ceiling omnidirectional mount is included and stand kits are available for portable operation. System includes(1) WIR TX9 DC emitter(1) TFP 053 power supply(1) BKT 024 wall/ceiling mount(1) WCA 123 50' power extension cable(1) WCA 084 100' RG58 coax cablefeaturesNow with improved range up to 30000 sq ftElimination of wall-mount power supplyFully compatible with previous generationsspecificationswir tx9 dc architectural and engineering specificationsThe emitter shall be contained in a metal enclosure with a shatter-resistant lens.The emitter shall include an omni-directional mounting bracket for permanent installation and a bracket shall be available for mounting on a floor stand for portable installations.Each emitter shall be powered by a universal power supply with an output of 24 VDC 1.0 A 25 W.The power connector shall be a barrel style.The emitter shall have a BNC-type 50 ohm baseband input and 2 BNC-type baseband 50 ohm output jack.The emitter shall have a repeater circuit to allow multiple numbers of emitters to operate from the baseband signal.The emitter shall have a visible LED indicator for power and for baseband signal. Carrier frequency is 2.3 MHz to 3.8 MHz.The emitter shall shut off when the baseband signal is not present.The emitter shall provide an effective coverage area of up to 30000 sq ft (2787 sq m) in single-channel mode and up to 19000 sq. ft. (1765 sq. m.) in two-channel mode when using the RX22-4 or RX18 receivers.The emitter shall be convection-cooled without fans.The emitter shall have CE FCC RoHS and WEEE approval and carry a five-year warranty on parts and labor.The emitter shall be Williams Sound model WIR TX9 DC.wir tx9 dcDimensions Weight: 11.25 W x 6.25 H x 2.125 D (28.6 cm x 15.9 cm x 5.4 cm) 1.8 lbs (0.8 kg)Color: Black with white legends black acrylic lens (optional white enclosure available)Power Supply:Desktop-style universal power supply.Input: 100-240 VAC 50/60 Hz 0.6A. Line cord specified by country of use.Output: 24 VDC 1.0 A 25W. Barrel connector.50 ft DC power supply extension cable available (WCA 123).Carrier Frequency: Accomodates baseband sub carriers from 2.3-3.8 MHzEmitter IR Power: 3.5 wattsCoverage Area:30000 sq. ft. (2787 sq. m) in single channel mode when using the RX22-4 Receiver19000 sq. ft (1765 sq. m) in two channel mode when using the RX22-4 Receiver11000 sq. ft (1022 sq. m) in four channel mode when using the RX22-4 Receiver3350 sq. ft (311 sq. m) in single channel mode when using the RX18 ReceiverBaseband Indicator: Red LEDPower Indicator: Red LEDAuto Carrier Shut-Off: Turns off LEDs when no baseband is presentPower Input: 24 VDC 0.8 ABaseband Input: BNC 50 ÃŽ© for use with MOD 232 TX 90 TX 90 DC TX 9 and TX 9 DCBaseband Output: BNC 50 ÃŽ© for use with TX 9 or TX 9 DC onlyBaseband Cable: RG 58 Coax BNC Connectors maximum 1000 ft (300 m) length.Operating Requirements: 32-122 째F (0-50 째C) ambient temperature non-condensing non-corrosive atmosphereMounting Kits:Wall or Ceiling Mount: BKT 024 Omnidirectional mount;Optional: Tripod Stands:Ë€ SS-11 or SS-6Warranty: 5 years on transmitter (90 days on accessories)Approvals: CE FCC RoHS WEEECompatible Receivers:WIRË€ RX22-4 Four-Channel ReceiverWIRË€ RX18 Two-Channel ReceiverNotes: Specifications:Ë€ Single end input volume &Ë€ tone controls at mid point 1 kHzMusic Preset
