NUX B-6 Pro Digital 2.4GHz Wireless System for Wind Instruments

Go Wireless. Play Freely. Sound That Moves With You. The NUX B-6 PRO Wireless System for Wind Instruments is a compact yet powerful solution for performers who need freedom of movement without compromising sound quality. With signal transmission up to 165 feet (50m) and an ultra-low latency of just 3.6ms, it delivers professional-grade 24-bit/48kHz audio, ensuring your performance is heard clearly whether onstage or in motion. No cables. No boundaries. Just pure expression. SPECIFICATIONS: Microphone Microphone Type: Condenser Polar Patterns: Cardioid Microphone Sensitivity: -51dB TX (Transmitter) / RX (Receiver) Operating Frequency Band: 2400-2483.5MHz RF Output Power: Maximum 10mW E.I.R.P Transmission Distance: Up to 165 feet line-of-sight Latency: 3.6ms (Low Latency), 6.1ms (Default), 9.9ms (Stable) Sampling Depth / Sampling Rate: 24bit/48kHz Frequency Response Range: 20Hz-20kHz Maximum Audio Signal Output: 6.4dBV (Send/Output) THD+N: <0.01% (Typical) Dynamic Range: 112dBA (Send/Output) Battery Capacity: - TX (Transmitter) 3.7V/500mAh - RX (Receiver) 3.7V/3000mAh Battery Life: - TX (Transmitter) up to 7 hours - RX (Receiver) up to 11 hours Power: DC9V, 1A (minimum), negative tip power supplies (Receiver) Auto Power Off: Automatic power off after 10 minutes of no wireless connection Dimensions (L x W x H): - TX (Transmitter): 61 x 60 x 30mm - RX (Receiver): 93 x 120 x 60mm Weight: - TX (Transmitter) excluding microphone: Approximately 60g - RX (Receiver): 420g Engineered for Wind Instruments Engineered specifically for saxophones, trumpets, and other brass/woodwind instruments, this system tackles the unique challenges wind players face. Its precision clamping system contours perfectly to the instrument’s bell or mouthpiece, ensuring a secure, non-invasive fit that doesn’t interfere with your performance. This thoughtful innovation solves the long-standing challenge of unreliable mic placement during live shows, delivering clean, consistent audio capture, so your sound is as expressive as your playing, maintaining full artistic freedom. Effortless Setup with Auto Pairing & Frequency Hopping The NUX B-6 PRO takes the hassle out of setup with its automatic pairing, just power on the transmitter and receiver, and they'll sync in seconds. It also features intelligent frequency hopping technology, which automatically scans and switches to the most stable signal. This ensures seamless, interference-free wireless transmission, even in crowded performance environments. Extended Range, Ultra-Low Latency for Pro-Level Performance Equipped with next-generation wireless transmission technology, the NUX B-6 PRO is designed to deliver exceptional signal stability and responsiveness. With a maximum range of up to 165 feet and latency as low as 3.6ms, it ensures that your performance stays in perfect sync, whether you're on a large stage or moving through a dynamic venue. The system allows you to optimize transmission settings in real-time, choosing between Low Latency Mode for ultra-fast response or Stable Mode for enhanced signal reliability in challenging environments. This balance of speed and stability makes the B-6PRO ideal for both live shows and professional studio sessions. Patented Shock-Absorbing Gooseneck Microphone Design The NUX B-6 PRO introduces a newly engineered shock absorption system, specially designed to minimize unwanted resonance and handling noise during live performance. This patented gooseneck structure effectively isolates the microphone from mechanical vibrations and button clicks, ensuring that what your audience hears is only your playing, not the distractions. At it's core is a custom unidirectional electret condenser microphone, delivering clear, detailed, and focused sound capture tailored specifically for wind instruments. Quick Installation with a Secure, Instrument-Friendly Clamp Design It features a custom-designed clamp structure tailored specifically for wind instruments. Engineered for fast, hassle-free setup, the clamp includes a flexible, rubber-coated contact grip that securely attaches to the bell of saxophones, trumpets and other brass or woodwind instruments. This thoughtful design ensures stability during movement while protecting your instrument’s finish, giving you reliable performance without compromise. Gentle, Non-Slip Contact The soft rubber-coated contact points prevent direct metal-to-metal friction, eliminating scratches and wear while enhancing both safety and stability. Long Battery Life with Convenient Magnetic Charging The NUX B-6 PRO is built for long sessions with high-capacity lithium batteries in both the transmitter and receiver. Enjoy up to 7 hours of continuous playtime on a full charge, ideal for rehearsals, gigs, or studio tracking. When it’s time to recharge, simply place the transmitter on top of the receiver for effortless magnetic charging. No cables, no hassle, just smart, reliable power that keeps up with your performance. Professional EQ Presets for Every Wind Instrument This system features a range of professionally tuned EQ presets, each optimized for different wind instruments. Whether you’re playing saxophone, trumpet, or any brass/woodwind, simply select a preset with one click to achieve perfectly balanced, clear tone, without the need for external tweaking. Built-in Multiple Functions The NUX B-6 PRO has a digital tuner designed for wind instruments, a booster effect, and send/return functionality, all of which can be individually controlled through the footswitch setting. Connections USB Audio You can connect the B-6 PRO to a mobile phone via the USB-C port for digital audio recording. *Tips: Some mobile devices may require an OTG adapter to connect with the B-6 PRO Customize Your Own Boot-up Picture B-6 PRO allows you to customize GIF boot-up animations! Follow these steps to set it up: Download the "NUX B-6 PRO GIF Customizer" software from the Support section below and install it. Use the included USB cable to connect the B-6 PRO RX (Receiver) to your computer. Launch the GIF Customizer software and follow the prompts to upload and save your GIF to the device. Disconnect the USB cable and restart the RX. Navigate to Menu > Display Settings > Boot-up Animation and select "User Image". Now your B-6 PRO will greet you with your favorite animation every time you turn it on! ** Free Firmware Updates and Manuals are available by clicking here then selecting "Support"
